Name: FS series Square vibrating screen

Keywords: FS series Square vibrating screen
Description: SummaryThe machine is composed of three parts: the inlet and outlet, screen, screen box, vibration source and shock absorber. The frame is connected with the sieve box with 4-6 sets of soft rubber shock absorbers fixed up and down. The centrifugal force is…

Details

Summary

The machine is composed of three parts: the inlet and outlet, screen, screen box, vibration source and shock absorber. The frame is connected with the sieve box with 4-6 sets of soft rubber shock absorbers fixed up and down. The centrifugal force is generated when the power is switched on, and the amplitude is provided with an eccentric block and a shock absorber corresponding to control, so as to achieve the best working performance required to make the material have a shock and loose screening process. Widely used in pharmaceutical, food, chemical, metallurgical, electronic and other industries to screen the ideal equipment.
Technical specifications

Model

Capacity
kg/h

meshes
(mesh)

Motor power
(kw/h)

Vibration frequency
(r/min)

Exciting force
(kN)

Upper outlet height

Middle exit height

Lower exit height

Overall dimension
(L×W×H)

Weight
(kg)

FS-0.5M2-X

450

2-150

0.2×2

1400

0-2.5×2

800

680

500

1300×770
×1060

220

FS-0.7M2-X

650

2-150

0.2×2

1400

0-2.5×2

850

750

530

1700×680
×1100

280

FS-0.8M2-X

750

2-150

0.2×2

1400

0-2.5×2

850

750

530

1600×830
×1150

320

FS-1.2M2-X

1100

2-150

0.2×2

960

0-5×2

880

760

520

1900×980
×1220

450
